The luxury touch you deserve is provided by PNW’s Range handlebars and Marin CNC stem, while a jump-busting Manitou Circus Expert fork smoothes landings. Its Series 3 aluminum frame is spin-it light and big-line durable. Because of its low, compact frame and short chainstays for poppy manuals, its shape allows you to level up without boundaries.
Specifications
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION
Frame
Series 3 6061 Aluminum, 26” Wheels, 135x10mm Horizontal Dropouts, 73mm Threaded BB, ISCG 05 Tabs
Front Suspension
Manitou Circus Expert, 26″, 100mm Travel, Coil Spring, Taper Steerer Tube, 20x110mm Thru Axle
Rim
Marin Custom Extrusion, 27mm Inner, Pinned Joint
Hub Rear
Forged Alloy, 135x1mm, Bolt-On, Quad Sealed Bearings, Disc, 32H
Hub Front
Forged Alloy, 110x20mm, Disc, 32H
Spokes
14g Black Stainless Steel
Tires
Vee Tire, XCV 26×2.25”, LSG Compound, Wire Bead
Crankset
Marin Forged Alloy, Alloy 32T Chainring, 104mm BCD, 170mm Crank Length
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC HL-1
Cassette
14T Single Speed Cog
Brakes Front
–
Brakes Rear
Tektro HD-M535, 4 Piston Hydraulic Disc, 160mm Rotor
Brake Levers
Tektro HD-M535 (Rear only)
Handlebar
PNW Range Handlebar, 38mm Rise, 35mm Clamp, 800mm Width
Stem
New Marin CNC Stem, 35mm Clamp
Grips
Marin Grizzly Lock-On
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8″ x 1 1/2”
Seatpost
Marin Alloy, 30.9mm
Saddle
Marin DJ Saddle
Pedals
Alloy Platform
Extras
All New Marin Chain Tension Device
