The Series 3 Aluminum frame handles tight woodland trails and open singletrack. The X-Fusion’s travel-adjustable dropper complements jaw-dropping Marzocchi, Shimano, and Maxxis components.
* The manufacturer’s suggested retail price excludes shipping, packing, and US sales tax. Please contact your nearest Marin dealer for a price.
Specifications
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION
Frame
Series 3 6061 Aluminum Frame, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Front Suspension
Marzocchi Bomber Z2 29″, Rail Damper with Sweep Adjustment, 140mm Travel, Kabolt Bolt-On Axle, 44mm Offset
Rear Suspension
Marzocchi Bomber Air Inline, Custom Tune, 210x55mm, 25xM8 Upper & Lower Mount
Rim
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
Hub Rear
Shimano HB-MT501B, 148x12mm, Centerlock, Micro Spline Freehub Body
Hub Front
Shimano HF-MT500B, 110x15mm, Centerlock
Spokes
14g Black Stainless Steel
Tires
Front: Maxxis Assegai MAXX GRIP, 2.5″ EXO+ Rear: Maxxis Minion DHR II, MAXXTERRA, 2.5″ EXO+, Tubeless compatible
Derailleur Rear
Shimano Deore, 12-Speed, SGS
Shift Lever
Shimano Deore, 12-Speed, SL-M6100-R
Crankset
Marin Forged Alloy, Integrated Steel 30T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X-12 Silver and Black
Cassette
Shimano, Deore M6100, 12-Speed, 10-51T
Brakes Front
Tektro M5140 Hydraulic, 200mm Rotor
Brakes Rear
Tektro M5140 Hydraulic, 180mm Rotor
Brake Levers
Tektro M5140 Hydraulic
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 40mm Rise, 5º Up, 9º Back
Stem
Marin 3D Forged Alloy, 55mm
Grips
Marin Grizzly Lock On
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8″ x 1 1/2”
Seatpost
Tranz-X YSI60QL Dropper Post, Adjustable Travel, 30.9mm Diameter, S = 150MM / M = 170MM / L-XL = 200MM
Saddle
Marin Speed Concept
Extras
Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head
