It has 26″ wheels, which are somewhat smaller than our full-size bikes, making it an ideal first ride for tweeny riders. And, like the ‘grown-up’ Rift Zone, it boasts 130mm of rear travel, a lightweight aluminum frame, and our super-plush MultiTrac suspension platform for unlimited trail adventures.
The Rift Zone 26 uses the same frame, fork, and shock as the Rift Zone 24. Simply switch the wheels and cranks to reduce it to 24″” for the ideal hand-me-down.
Specifications
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION
Frame
Series 3 6061 Aluminum, 26” Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Front Suspension
X-Fusion Velvet RLC 26″, 130mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Rear Suspension
X-Fusion O2 Pro R, 190x45mm, Custom Tune, M8x22.2mm Hardware
Rim
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Hub Rear
Joytech 141 QR, Standard Freehub Body
Hub Front
Joytech, 100x15mm
Spokes
14g Stainless Steel
Tires
Vee Tire Co, Flow Snap 26×2.4″, Tackee Compound, Wire Bead
Derailleur Rear
Shimano RD-U6000, 11-Speed GS
Shift Lever
Shimano, SL-U6000-11R, 11-Speed
Crankset
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearing
Chain
Shimano LG-500 11-Speed
Cassette
Shimano CS-LG400-11, 11-Speed, 11-50T
Brakes Front
Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Brakes Rear
Tektro HD-M280 Hydraulic Disc, 180mm Rotor
Brake Levers
Tektro HD-M280
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 12mm Rise, 720mm Width, 4º Up, 9º Back
Stem
Marin 3D Forged Alloy, 35mm
Grips
Marin MTN, Closed End
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8″ x 1 1/2”
Seatpost
X-Fusion Manic LC, 1x Composite Remote, 100mm
Saddle
Marin Speed Concept
Extras
Closed 9-12 Thru-Axle Bolt On System
